Stable 100 Ton Ultra-Large Capacity Output: Delivers consistent 100 tons of plate ice per day, solves the pain points of insufficient continuous ultra-large ice supply and unstable full-load output for mass concrete pouring, super large cold chain hubs and large-scale fishery processing bases, ensuring uninterrupted operation for large projects.
Modular Customizable Design: Adopts flexible modular structure, solves the pain points of difficult transportation, complex on-site installation and inflexible capacity expansion of ultra-large ice making equipment, supporting customized combination according to site conditions and business needs.
High-Efficiency Energy-Saving Performance: Optimized heavy-duty refrigeration system, solves the pain points of high energy consumption and excessive long-term operating costs of ultra-large capacity equipment, greatly reducing energy consumption while ensuring full-load stable operation.
Heavy-Duty Industrial Durable Build: Reinforced anti-corrosion industrial structure with premium core components, supports 24/7 continuous full-load operation, fixes frequent breakdowns, high maintenance costs and short service life issues under high-intensity working conditions.
Full-Scene Wide Adaptability: Perfect for large-scale concrete cooling in water conservancy, nuclear power and bridge projects, super large cold chain logistics, bulk food processing, ocean fishery processing and other heavy-duty industrial scenarios.
Full-Cycle Customized Service Support: Directly supplied by Icesta professional ice equipment manufacturer, provides one-stop customized solution design, on-site installation and commissioning, and global full-cycle after-sales service, eliminating your worries about technical support for ultra-large equipment.

After-sales Service:

1 Year

Certification:

CE ISO9001

Ice Thickness:

8-10mm

After-sales Service Provided:

Service Machinery Overseas

Inquiry

Write a Review

Product Introduction

Icesta plate ice is an irregular plate-shaped ice . It is a transparent crystal and is not easy to melt. The surface is small,
dry, powder-free, and has a long cooling time. The size of the sheet is about 40×40mm to 80×80mm, which can be adjusted according to the needs of customers. The thickness is about 8-10mm, and the thickness of the slab ice can be adjusted through the ice making time. The ice cubes are thick, have a long storage period, are not easy to melt, have good air permeability, and have a constant refrigeration temperature. The small slab ice is easy to use in any situation. With a secondary ice crusher, the size can be adjusted freely. Plate ice evaporator is mainly divided into two types: aluminum alloy plate ice evaporator and stainless steel plate ice evaporator. The plate ice evaporator uses a direct expansion system, using R-22, R507A, R404A or ammonia (R717) as the refrigerant.

ICESTA CONTAINERIZED PLATE ICE PLANT & AUTOICE STORAGE & DELIVERY & DOSING SYSTEM

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 8

Containerized Plate Ice Machine

1. CE Certification.
2. SS304 plate evaporator, SS304 frame, ice sanitary and edible.
3. Automatic producing process by PLC control, lower the cost on manpower.
4. Thickness of ice is adjustable, from 8mm to 10mm. 8mm is the one our customer like more.
5. High efficiency and energy saving, only consumes about 60KW.H/ton ice.
6. Mainly used in marine products preservation.
7. Long service life.
8. One year warranty, and lifetime service available.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 9

ICESTA Auto lce Storage Room

1 .Mobile type, starting from 20 metric tons up to 100 metric tons

2.Robust steel used for the ice rake assembly and Ice Rake Hoist System

3.Reliable Sensors and Limit Switches to control the movement of Auto Ice Storage Room Automatically

4.Efficient Air cooler to keep the room temp down to -l0 degrees

5.100- 150 mm thickness Pancls keep the cold inside the room

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 10

ICESTA lce Discharge Auger and Delivery Auger

1.Robust design suitable for severe working conditions

2.Single and Dual Screw Design, with a designed delivery rate of 25-40T per Hour

3.Renowned Gearbox with Motor ensures the high quality of ICESTA Brand.

4.Single or Dual lce outlet for one or two ice outlet, which can deliverice at sametime to twin batch plants.

5.Stainless material or Galvanized Steel optional.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 11

ICESTA Smart lce Dose System

1.Robust design suitable for severe working conditions
2.Ice Hopper volume up to 500KG
3.Renowned Gearbox with Motor ensures the high quality of ICESTA Brand;
4.Accurate lce Scale system

5.Stainless material or Galvanized Steel optional.

FEATURES OF ICESTA ICE/COLD WATER PLANT

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 12

FEATURES OF ICESTA ICE/COLD WATER PLANT

1. Environmental friendly refrigerants - R404A and R407C.

2. Multi-stage cooling from +45℃ down to less than 1℃ by 2 semihermetic screw/reciprocating compressors with economizer performance.

3.Plate heater exchanger as evaporators (corrosion-free) for high-efficiency heat transfer.

4.Stainless Ice tank (corrosion-free) for the ice bank system.

5.Evaporative condensers (corrosion-fee) for High efficiency heat rejection.

6.With our special designed multi-stage cooling system for fresh water cooling of concrete batching plants extraordinary high COP’ s can be achieved;

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 13

First Cooling Stage (for CWP and IWP Chillers)

Even under the most severe climatic conditions it is possible to cool water from practically any temperature down to 35℃ within a cooling fan without the involvement of a refrigeration system which reduces the actual cooling capacity of the compressors by 20 %. Thus this refrigeration capacity of the first stage is free of charge.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 14

Second Cooling Stage (for CWP and IWP Chillers)

Furthermore, it is much more efficient (by 25 %) to produce refrigeration capacity at an evaporation temmperature of +7℃ than at 0 C. Therefore the water is cooled from 35℃ down to 2℃ in the plate heat exchanger of the second stage by the first compressor.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 15

Third Cooling Stage (for lWP Chillers Only)

Finally in the Third stage the water is cooled from 2℃ down to less than 0.5°C in our special “ice bank system” by the second compressor. This system consists of a stainless steel water tank in which film heat exchanger is installed. Around these heat exchanger ice can be accumulated without destroying the system. The water is circulated around these heat exchanger covered slightly with ice.In that way the water temperature is between 0℃ and 1℃

Technical Parameters

*Power supply: 380V/3P/50HZ,220V/3P/60HZ,380V/3P/60HZ,460V/3P/60HZ

*Ambient temperature 35°C

* Water supply Temp 20°C( quality)
*Extreme working condition environment: 5°C~40°C, water supply 5°C~30°C

*Refrigerant: R22,R404A, R507A

Model	IP30T-R4E	IP40T-R4E	IP50T-R4E	IP60T-R4E	IP70T-R4E	IP80T-R4E
lce production	30t/24hrs	40t/24hrs	50t/24hrs	60t/24hrs	70t/24hrs	80t/24hrs
lce temp	-5°C	-5°C	-5°C	-5°C	-5°C	-5°C
Cooling capacity	277KW	355KW	397KW	502KW	628KW	710KW
Compressor power	108KW	149KW	164KW	206KW	266KW	298KW
Input power	123KW	168KW	188KW	231KW	300KW	334KW
Evaporator qty	24	24	30	30	30	32
Evaporator size	2200*1000mm	2440*1050mm	2440*1050mm	3000*1050mm	3350*1050mm	3500*1100mm
Cooling type	Evaporative cooling
lce storage capacity	90t
lce storage system power	33KW
Amount of ice delivered	15t/h
Container size	1240025002900mm

Test report of Plate ice machine

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 16

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 17

Application Industry

More and more Coling or temp.Reduction industry used the ice machines to meet their higher technic request due to their deeper knowledge about this equpment.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 18

Auxiliary Equipment

Fully automatic system "storage" and "ice delivery" integration project

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 19

Drawing Display

The ICESTA team has used more than 20 years of experience in refrigeration and ice making to continuously innovate products to achieve higher efficiency, more stable operation, smoother ice removal and ice production, over 20 technicians provide life time service.

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 20

Engineering Case

Since 2007, ICESTA products have been sold to more than 80 countries around the world, and provide distributor services in many regions.

30T flake lce Plant & 50T Auto Storage, Humpty Doo Baramundi Australia

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 22

Plate Ice Machine 100 Ton Ultra-Large Capacity Heavy-Duty Industrial - ICESTA 23

Picture Display

Technology, change the world, innovate, and subvert tradition. We are committed to making people's production and life more convenient, efficient and beautiful
